1KW Fiber Laser Tube Making Machine Pipe Mould Fixture With PLC Control System

Ask Latest Price
Video Channel
Brand Name :Questt
Model Number :QA-ZP40
Certification :ISO CE
Place of Origin :China
MOQ :1 set
Price :Negotiable
Payment Terms :T/T, Western Union, L/C
Supply Ability :3000 set per year
Delivery Time :10-30 days
Packaging Details :Wooden cases
Application :pipe making
Laser power :1 KW
laser type :fiber laser
pipe diameter :9-51 mm
thickness :0.2-1 mm
Garranty :1 year
more
Contact Now

Add to Cart

Find Similar Videos
View Product Description

Pipe Making System with 1KW Fiber Laser Welding after bending

The system is consist of

1. Pipe making machine

2. 1KW fiber welding machine

3. Pipe mould fixture

Specification

5. Pipe rangeΦ9~Φ50.8mm, Thicknessδ0.2-1.0mm

6. Pipe moving speed range: ≤12M/min

7. Drive motor(Siemens motor ,Frequency control) 7.5kw. Voltage: 3 Phase 400V 50Hz

Configuration

A. Pipe making machine

1. Pipe making machine has the double coils loading frame, Diameter of coiler Ф350-Ф550mm ,Loading capacity 1.5T.

2. Forming stage:

(1)Feeding guide 2 sets: By feeding device and three roller leveling device to feeding. 1 set

(2)Vertical holders, 7 sets. The main axle uses the 40Cr, and with tempering, high frequency quench, accurate grinding, rust prevention. The holders are use HT200 material.

(3) Pipe making machine diameter of vertical axlesφ40mm, Diameter of Horizontal axlesφ25 mm, Straightening axles φ30.

(4)Horizontal type holder, 8 sets. The main axle uses the 40Cr,and with tempering, high frequency quench, accurate grinding, rust prevention. The holders are use HT200 materi(4)Spiral gear box drive system ,1set;

(5)Basic, 1 set

(6)212 universal drive shaft connecting for cars.

B 1KW Fiber laser welding system 1 set

1. 1KW Fiber laser System from Raycus China

2. Special fiber laser cooling system

3. Laser welding head from LaserMeck US

4. Laser welding gas protect system

5. Special welding controller and industry computer

6. PLC control system

7. Laser welding head up and down worktable

8. Special control cabinet

C. Grinding equipment

(1)Grinding head ,3 Sets; Motor power 3kw

(2)Horizontal holder ,2 Sets

(3) Basic ,1 Set.

D. Sizing and straightening machine

(1)Vertical holders, 4 sets; (2)Horizontal type holders, 4 sets;

(3)Straightening head,2 sets;(4)Spiral gear box drive system, 1 set;

(5)Mainly motor

E. Automatic cutting system

(1)Metal saw circle cutting blade.

F. Finished frame, 1 set.

G. Electrical control system

(1)Electrical control system for the pipe machine, 1 set; (2)Stop button;

(3)With frequency converting control system

H. Rank for the machines

V: Horizontal H: Vertical Q: Grinding Heads TH1,TH2 : Straightening Frame

Machine overvice
